Radar sensors for collision avoidance
The Radar Sensor uses FMCW radar technology to detect stationary objects and people in blind spots. This advanced system alerts the operator with both visual and audible warnings.The system has three distinct length and width modes, enabling the operator to adjust the Display Unit to fit their needs. The system’s capability of being able to determine whether an object is approaching or moving away from the sensor, helps to limit the number of false detections caused by objects of no concern encroaching on the detection area. The commercial grade heavy-duty system has an IP69K waterproof rating, a simple installation, and works perfectly in all weather conditions.
The Radar Sensor uses FMCW radar technology to detect stationary objects and people in blind spots. This advanced system alerts the operator with both visual and audible warnings.
The system has three distinct length and width modes, enabling the operator to adjust the Display Unit to fit their needs. The system’s capability of being able to determine whether an object is approaching or moving away from the sensor, helps to limit the number of false detections caused by objects of no concern encroaching on the detection area.
The commercial grade heavy-duty system has an IP69K waterproof rating, a simple installation, and works perfectly in all weather conditions.
FEATURES
-
Programmable Radar sensor
-
Transmit frequency : 24.06 ~ 24.22 GHz
-
Modulation : FMCW
-
Detection zone : 5 Zones
-
IP protection rate : IP 69K
-
Vibration : 15G
-
3 x detection mode adjustable with display unit
-
Detection Mode1 : 3.0 x 5.0 meter
-
Detection Mode 2 : 4.0 x 6.0 meter
-
Detection mode 3 : 6.5 x 9.0 meter
Radar sensor for heavy-duty vehicles
Integrated RADAR SENSOR and CAMERA Combo System with 7-inch AHD monitor
The Radar & Camera Combo System uses 24GHz FMCW technology to detect stationary object and people in blind spots. The radar-integrated camera provides both blind spot image and audible waring to the driver to prevent accidents.
It assists drivers by notifying them of other vehicle as well as obstacles they may miss. You do not have to install camera and radar respectively. Just install one housing and connect one cable from the Radar & Camera Combo System to a radar monitor. The smallest radar-integrated camera system is commercial grade as well as IP 69K waterproof rating.
-
FEATURES
-
All-In-One radar camera
-
Provide image and audible waring signal
-
24GHz FMCW technology
-
1080P (Full HD)/ F.O.V :140°
-
Night vision (IR LED & CDS sensor)
-
TDN : True Day & Night
-
Directional Sensing to minimize false alarm
-
Detection range : 4 3 x 4.0 meter
-
Waterproof and rugged design
Programmable RADAR
Programmable
Radar Sensor/Camera
The models (RM-02, RM-06 and RC-06) are programmable, in other words, "switchable" between the 3 detecting range modes. The feature might bring forth ease of use and cost-performance as a whole, if only users can endure the "comparatively longer vertical radar spread angle". These programmable ones have comparatively longer vertical radar spread angle and shorter horizontal one.
